Grain storage facilities: Planning for Efficiency and Quality

A Grains Industry Guide

Overview Feat

Overview and introduction

Screen Shot 2013-05-20 at 3.33.35 PMGrain storage systems come in a range of shapes and sizes to meet farm requirements and careful planning is needed to optimise an on-farm grain storage facility investment. According to the option selected, on-farm grain storage systems can provide a short-term or long-term storage facility. Depending on the goal of on-farm storage, whether it be access to improved markets or simply to maximise harvest efficiency, there are a number of options available.

Harvest is the ideal time to plan future grain storage system requirements, as it can help identify issues and opportunities for future harvest operations that may otherwise be forgotten once next year’s crop cycle gets underway. Costs and storage flexibility can vary between grain storage options as can longevity of the investment. Table 1 identifies the major on-farm grain storage options, their advantages and disadvantages.


Fig 1 - Farm Grain Storage




Silos are the most common method of storing grain in Australia, constituting 79% of all on-farm grain storage facilities nationally (see Figure 1).

Silos come in a variety of configurations, including flat-bottom or cone base, and both are available as gas-tight sealable or non-sealed, aerated and non-aerated. The balance of on-farm grain storage facilities can be split between grain storage bags (9 per cent) and bunkers or sheds (12 per cent). Grain-storage bags are increasing in popularity as a short-term storage solution to assist harvest logistics. With careful management growers can also use silo bags to provide short-term marketing opportunities. For similar storage time-frames to grain storage bags, and where options are limited, growers can also use sheds to temporarily store grain during harvest — provided they have been well prepared.

Superior silo: The dominant on-farm grain storage option is the silo in either a flat-bottom or cone-base configuration. Superior silo: The dominant on-farm grain storage option is the silo in either a flat-bottom or cone-base configuration.


Benefits and pitfalls of various storage types

Silos: fumigation options

A gas-tight sealable silo will ensure phosphine, or other fumigants and controlled atmospheres, are maintained at a sufficient concentration to kill insects through their complete life cycle of eggs, larvae, pupae and adult. Be aware of cunning marketing terminology such as ‘fumigatable silos’. Although such a silo might be capable of sealing with modifications, a gas-tight sealable silo needs to be tested onsite to meet Australian Standard (AS 2628-2010) after installation. Gas-tight sealable silos also can be used for alternative methods of insect control including controlled atmospheres of inert gasses, such as carbon dioxide or nitrogen. Current costs of using these gases (between $5 and $12/tonne to treat stored grain compared with $0.30 per tonne using phosphine) carbon dioxide and nitrogen atmospheres will arguably be used solely by niche growers, such as organic growers, until gas is less expensive.

There is significant work being carried out in lower-cost nitrogen gas generation and if buying a silo, ensure it is gas-tight for future proofing of the investment.


Silos: sizes and construction

Silos can be transported fully constructed and ready to stand, or can be built onsite. While intra-state variations apply, transportable silos are typically limited to 140 tonnes capacity due to road transport regulation limitations. Most smaller, 50–70t, cone-bottom silos are prefabricated and transported. Cone-bottom silos are easier to clean than flat-bottom silos due to their self-emptying design, but are limited to capacities less than 300t. Some growers require gas-tight storage facilities of greater capacity and increasing silo capacity requires quality materials and design. Silos can be built onsite and are available in sizes up to 3000t. The increased surface area of a larger silo requires more sheet metal joins, providing more opportunity for gas to escape.

TABLE 2 Typical Grain Bulk Densities Per Cubic Metre
TABLE 2 Typical Grain Bulk Densities Per Cubic Metre

Built to capacity: Transportable prefabricated silos are available up to 140t capacity, while silos can be built onsite to store thousands of tonnes, but are harder to seal.

Silos: lifespan

Silo lifespan is another advantage delivered through investment in gas-tight sealable silo storage infrastructure. A well-built, aerated, quality gas-tight sealable silo constructed to meet the Australian standard (AS 2628-2010) with a thorough maintenance regime could be expected to provide around 25 years of serviceable life before major repairs may be required. Silos: aeration While some preliminary research has been carried out using other grain-storage methods, silos permit simple administration of aeration after harvest to cool grain.

Aeration cooling of grain in-storage creates uniform moisture conditions and slows or stops insect pest life cycles.

Depending on the temperature reductions achieved; this can deliver significantly-reduced insect numbers.

Cool it: aeration cooling is relatively cheap and can offer substantial benefits.For older, unsealed silos, consider retro-fitting aeration as the first option. Aeration cooling requires airflows of at least 2-3 litres of air, per second, per tonne. For example, a 100t silo will require 200-300 litres per second (l/s) of air to cool the grain effectively. Aeration fans also require well-designed perforated ducts or a plenum to assist in dispersing airflow evenly throughout the silo. Selecting the coolest air for the grain is best done using an aeration controller, but aeration fans should be run continuously for at least three days for smaller silos (less than 100t) and up to a week for large silos (over 100t) as soon as grain covers the aeration ducting. This initial process removes the harvest heat and equalises grain moisture. After initial harvest heat has been removed, the controller can be switched on to continue the cooling process.

Silos: aeration drying

Keeping dry: specific drying silos are designed to maximise drying efficacy and have minimum air-flow rates of between 15–20l/s/t of storage.Specific drying silos are designed to maximise drying efficacy and have minimum air-flow rates of between 15–20 litres per second per tonne (l/s/t) of storage. Specially-designed drying silos often have a truncated, or secondary, base cone to assist in the efficiency and efficacy of drying stored grain.  Drying with ambient air requires a relative humidity well below that of the equilibrium relative humidity of the grain. Drying silos often allow the addition of heat at the air intake to improve the moisture removal capacity of the air flowing through the grain.

Silos: capital investment

As a permanent infrastructure fixture on a farm, silos are initially one of the most expensive options of grain storage at around $100 to $140/tonne for transportable sealed silos. To this can be added foundation requirements, which can vary between $2500 for a 70t transportable silo to considerably more for a flat-bottom silo with aeration ducting incorporated into the floor. Larger silos built onsite typically have an outlay cost of about $80 per tonne of stored grain. But looking at this investment over the life of the storage can see this figure drop significantly to being one of the cheapest forms of on-farm grain storage.

Silos: safety

Safety first: caged and platformed access ladders improve safety when climbing the silo to inspect stored grainWorking at heights can be dangerous without the appropriate safety precautions. In the case of silos, this can mean working up to 16m off the ground. A climb to the top is required for regular inspection through the top hatch if grain is stored for more than a month. Silo designs now incorporate ground-operated lids, caged ladders, platforms and top rails to minimise the risk of operators falling. Facilities for harness attachments, which should be worn by all operators climbing silos, are also fitted.

Silos: retro-sealing

To meet the requirements of fumigation and utilising existing silo infrastructure, some growers have invested in retro-sealing older silos. In most instances these silos are high capacity (> 500t), flat-bottomed silos. Retro-sealing specialists use an array of rubber, specialised rubberised cements and silicon compounds to seal sheet joins, bolts, rivets, lids and openings on older silos. These are typically sprayed on with an air-operated gun with coarse flows to handle the heavy product viscosity.

[box]The interface between the pad and the bottom sheet of the silo and the top sheet meeting the roof should be given special attention as they are commonly points of limited seal integrity. Customised sealing plates can also be fabricated for doors, vents and openings. Oil-filled pressure-relief valves will also be fitted. The cost of retro-sealing an older style silo can be significant, often totalling as much as 50 per cent of the cost of a new sealed unit. Ensure the retro-seal contractor includes a guarantee that when completed the silo will meet the Australian Standard for sealed silos AS2628. After sealing, consider ongoing maintenance costs. Check coating integrity annually and patch as required to maintain an effective seal. Particular vigilance is needed around the storage base, and where the walls meet the lid, as expansion and contraction of the metal can damage the retro-seal finish.[/box]

 Silo buyers’ checklist

  • Aerated, gas-tight sealable silos should always be the preferred option.
  • Ask the manufacturer to provide a guaranteed pressure test in accordance with AS2628-2010 on-site after construction or delivery. Pressure testing a storage when full of grain is also important.
  • Ensure a pressure relief valve capable of handling the maximum air-flow in and out of the silo due to ambient temperature variations is fitted.
  • A silo aeration fan can be used with care to pressurise a sealable silo to carry out the annual pressure test for leaks.A tyre valve or a larger fitting may also be installed to determine the volume of air required for the test.
  • Seal mechanisms on inlets and outlets should be simple to operate and provide even seal pressure.
  • Seal rubbers should be quality high-density EPDM (ethylene-propylene-diene-monomer) rubber, maintain a strong memory and be UV resistant.
  • Look for ground-operated lids that provide an even seal on the silo inlet.High-quality ground-opening lids will provide a gas-tight seal, but some will still require a climb to the top of the silo to lock down the lid for fumigation.
  • Aeration cooling fans are a must-have accessory for a new silo and provide significant benefits for stored grain.Buy these with the silo or as an aftermarket accessory and specify airflow rates of at least 2–3l/s for every tonne of grain storage capacity of the silo.
  • Aeration drying silos are an option, but are typically shaped to maximise drying efficiency.Drying fans need to deliver between 15 and 20l/s for every tonne of grain storage capacity of the silo and additional sealable venting in the roof should be fitted.
  • Outlet access for unloading should be simple to operate and permit ample auger access.
  • Look for a sturdy base and frame on elevated cone base silos with quality weldments. Galvanised tubing has a heavier coating than galvanised rolled hollow section (RHS) but is more difficult to shape and weld joins.
  • Ensure wall sections incorporate a positive seal between sheets and sealed riveting where rivets are exposed.
  • Always consider access and safety features, including roof rails, ladder lockouts, platforms and ladder cages. It can be argued that a ladder should always be fitted, as inspection of the grain in the top of the silo should be carried out regularly.
  • A quality outside finish will provide a superior life. White paint reduces heating of grain in storage. It comes at a cost premium but is superior to zincalume finishes over time.
  • A chalk-board patch painted on the silo base can be useful for recording grain and treatment details, including variety, protein and moisture content, fill date and fumigation details.
  • Check silo design inside and outside for ease of cleaning. Check walls and aeration ducting including the floor for grain trap points.
  • Consider grain segregation requirements when determining silo size. Smaller silos allow better segregation.
  • Ensure adequate venting is fitted to the roof of silos with aeration fans to permit adequate air-flow without restriction. These vents should be easy to clean. Check seals and lock down if it is a sealable silo.

Sealing afterthought: retro-sealing silos is often less than the cost of a new silo but ongoing maintenance costs also need to be considered.

Grain-storage bags

Be prepared: Grain storage bags can provide a useful tool to improve harvest logistics but must be placed on a carefully prepared pad and be fenced off from livestock and wildlife.

As a relatively new on-farm grain storage option, silo bags have been widely used in Australia since the early 2000s, although they have been used overseas for much longer. As with most things new, numerous disasters, mostly due to operator error and lack of inspection vigilance, have earned grain bags a bad name. They can provide useful short-term storage (less than three months) and a logistics management tool during harvest. They must be installed on a well-prepared site away from bird habitats, including trees and water sources.

Grain-storage bags: capacity

Typical storage capacity is around 240 tonnes, but other sizes including 200t and 150t bags are also available.

Take care when buying bags. Quality of bag materials varies and using bags for grain storage that have been designed for silage storage is not recommended.

Grain-storage bags: using them successfully

Successful use of grain bags as an on-farm grain storage option requires a carefully-prepared pad. Anecdotally, an elevated, well-drained pad provides optimal results where no stubble (which can harbour vermin) or rocks can tear the grain storage bags as they are being filled and unloaded.

Fill rates are typically 3–4 tonnes per minute. Always fill bags up-the-slope and ensure brake settings on the filler are set to ensure the appropriate stretch of the bag is achieved. While typically a 10 per cent stretch, this can be adjusted down for hot weather conditions or up for cool ambient weather. When full, regularly and vigilantly check the bags for cuts, nicks and holes and patch these with silicon or bag sticky tape available from the bag supplier.

Grain-storage bags: costs

The two pieces of equipment required for loading and unloading grain storage bags can cost around $27,000 each. This equipment can be hired, although having your own can reduce the pressure of having to get grain in and out of the bags within a specified timeframe as demand for this hire equipment is high at the peak of harvest. The bags themselves are single-use and cost around $5 per tonne stored, or $1000 plus for a 240t bag. Consider site-preparation, including any earthworks and fencing requirements, time and labour costs for maintenance when calculating the comparative costs of using grain bags.

Grain-storage bags: useable lifespan

Grain-storage bags are best used for short-term storage only. While longer-term storages are possible, three months is regarded as a maximum storage period. Beyond this, there is considerable risk of grain losses and spoilage in many of Australia’s grain production regions.

Grain-storage bags: pest and insect control

Fumigation with phosphine in bags has been recently proven in Australia as an option if the correct method of application and venting is followed. Alternatively, fumigation of grain-storage bags can also be performed using gases like ProFume. But this is only available for use by licensed fumigators and the cost is generally considerably higher than phosphine. In addition to insects, vermin including mice and birds can attack grain bags. Outside baiting, reducing habitat provision and food sources (including regular checking and patching of bags where required) is the best way to reduce vermin risk. Grain storage bags: access One often-overlooked aspect of using grain-storage bags in the paddock is their accessibility after harvest. Unless the bags are placed on, or near, an all-weather access road, they can be difficult to unload if wet weather conditions prevail post-harvest. The pad site needs to be large enough for trucks and machinery for bag unloading and allow access in wet conditions.

Sheds and bunkers

Bunkers are commonly used by bulk handling companies, but require careful site preparation, labour for handling large tarp covers and machinery to move grain on and off the grain stack. Effective treatment of insect infestation is difficult in sheds and bunkers. For on-farm storage, grain bags may be a more suitable short-term alternative. Sheds can provide dual-purpose functionality for storage of other products including fertiliser and machinery. But the risk of grain contamination requires a focus on impeccable hygiene practices. As a permanent infrastructure investment, sheds can be continually used and have a retained value on-farm with a service life expected to exceed 30 years.

Specialist grain-storage sheds can be constructed to make filling and unloading simpler. Aeration and sealing methods for fumigations are best considered in the early shed design phase.

Sheds are most useful as a short-term storage solution to assist harvest logistics. They can be a useful component of an on-farm grain storage system that incorporates other gas-tight sealable grain storage facilities

Dual-purpose: Grain storage sheds can provide dual functionality but hygiene is imperative to avoid contamination.

Sheds: costs

Cost of grain storage in sheds varies widely depending on footing and slab requirements as determined by soil type. Method of construction and alternative uses can also vary the cost of construction. Sheds: aeration Aerating grain stored in a shed is difficult due to the open design of most shed structures. But customised ducting and air manifolds can be designed by grain aeration specialists to aerate grain stacked in a shed.

Sheds: pest and insect control

Given the open nature of most sheds on-farm, pest and insect control presents some challenges. Fumigation with gas-proof sheeting placed over the stack is difficult. Bulk handlers, including CBH in Western Australia, have invested heavily in sealing gas-tight bulk storage sheds to permit fumigation. On-farm, sheds are also prone to spoilage by mice and birds.

Sheds: loading and unloading

One of the biggest drawbacks of sheds used for grain storage is the ease of getting grain in and out. Using an auger or belt conveyor to fill the shed from the truck is common practice. For out-loading, some operators opt for bulk-handling buckets on front-end-loaders or tele-handlers to fill direct into trucks. Some grain trade operators use this approach to minimised grain damage when handling grains prone to splitting, such as lentils. Sump load points are occasionally used, with a lowered section of the floor utilising gravity to assist in sweeping grain into a loading point. Grain vacuums can also be used to out-load grain from sheds. Regardless of the out-loading options, inevitably, a final clean is performed with a broom and grain shovel, which can take time if hygiene is to be maintained.

Planning improves performance: careful planning can ensure your on-farm grain storage facility operates at maximum efficiency.

On-farm grain storage facility considerations

Depending on budget and expectations, investing in and planning a grain-storage facility requires a range of considerations, regardless of the storage type.

Access for in-loading and out-loading

Continuous loop roads around the grain-storage facility requiring minimal, or no, reversing are ideal and can dramatically improve loading and out-loading rates as well as minimising damage to equipment through accidental collision. Dedicate an ample-sized pad to permit auger or grain conveyor access and ease of shifting grain loads. Where steeper slopes exist, some growers have terraced the slope with a retaining wall, to allow them to reduce the lift height (and auger size) for loading the silo. Where retaining walls exceed 1m in height, consider guard rails and access steps.

Proximity to resources (power sources — electricity and fuel)

Whether the facility is to be powered for aeration, i.e. using petrol or electricity, consider the proximity to these resources, particularly if the facility will be built in stages as each stage becomes affordable. Connection to mains power can be expensive depending on the distance to the line. Some large drying fans also require three-phase power which requires a specific pole transformer.

 With augers, machinery and tipping trucks in use around the facility, placing power underground is expensive, but can significantly improve safety.

It is worth considering fuel sources and fuel lines for dryer installations, or future dryer installations, when planning the facility layout and constructing the pad.

Health and safety considerations

Operational safety considerations should be key to the facility design. Allow plenty of space for auger transport and movement around the facility.Ensure overhead power-lines are located nowhere near the pad where augers, conveyors or trucks might be operating — ideally locate power underground.

Pads should be flat, hard-packed stands that allow tipping trucks to elevate without risk of toppling over sideways.

Minimise any slopes and ensure they are of a constant grade. Position drainage lines and holes away from high-traffic areas to reduce the risk of equipment falling through while maximising drainage effectiveness. Electrical switch boards should incorporate residual current devices (RCDs) to prevent electrical shock if, for example, an electrical cable was accidentally cut. A qualified technician is required to  carry out any 240-volt electrical work. They will ensure the components are safe to use in areas where combustible dusts are present.

Road access

The ability to get trucks in and around the grain-storage facility is paramount to its success. Sealed or hard, all-weather roads to the site from a main road are essential for year-round out-loading, which will ensure grain sale contracts are met in a timely manner and can deliver marketing advantages. Proximity to trees and insect or bird havens Avoid locating storage facilities near trees, haystacks and haysheds. All are havens for insects and birds, making migration from nature to the grain stored in the facility easier. Similarly, water sources are attractions for vermin and birds. Avoid water sources when selecting a site for a grain storage facility.

Proximity to harvest locations

One of the most important considerations of facility placement and layout is harvest logistics. While placing silos close to a house or existing infrastructure is most common, it may not be the most efficient placement from a logistics perspective. More often than not, storage facilities are located according to proximity to power and facilities, so a balance between ease of accessing services and optimising harvest logistics has to be struck.

Determining storage capacity requirements

Calculating ‘adequate storage capacity’ can involve an enormous range of variables. Consider what would be the ’ultimate‘ in on-farm storage capacity for the farm and then plan a series of stages to achieve this ultimate goal. For some growers, ultimate storage capacity is 100 per cent of their harvest, while others will always use an external bulk handling system to some extent. This is likely to vary between State bulk handling operators, dominant crop types, target markets and distance from the farm to bulk handlers. As an initial step, aim for a reasonable proportion of the total harvest and plan to expand the facility from there. Consider investing in a number of small silos as the first step and buy larger silos as the business expands. Smaller silos, for example around 70 to 100 tonnes, will always be valuable for segregation and blending or insect control in small parcels of grain. Fumigating a small amount of grain in a large silo can be expensive because treatment is based on silo volume, not grain volume.

Determining out-loading throughput rates

A standard out-loading rate is around 3-4 tonnes per minute and anything exceeding that will enable the driver to get back on the road to their delivery port quicker.

Out-loading calculations: Aim for 3-4 tonnes per minute out-load to enable drivers to get back on the road and to minimise frustration. Keeping truck drivers waiting to load should be avoided wherever possible.


With fines for overloading increasing in severity and occurrence in most States, using a weighbridge could pay for itself quickly. Weighbridges can be incorporated into the silo load-and-unload loop with effective installations providing readouts for the driver when approaching from both sides. A weighbridge, fully installed will add a cost of about $130,000 to the facility.

Blending abilities

The ability to blend grains and optimise specifications is one of the primary benefits of an on-farm storage facility. The ease of out-loading for blending is greatly improved by adding a belt or drag-chain grain conveyor and elevator system to the facility. Grain can be simultaneously out-loaded from multiple silos and loaded into another. The alternative is to blend into a truck and then auger back, which can be fiddly but effective if small batches are blended occasionally.

Sampling abilities

Play it safe: The addition of a weighbridge can help maximise truck carrying efficiency and avoiding overloading fines.

Keeping a record and sample of grain stored on-farm can be useful for subsequent testing and quality assurance. Owners of larger on-farm, grain-storage facilities commonly add a sampling shed where grain-quality specifications are collected and stored. Taking the sample from silos can be easier if sealed silo ports for sample collection can be easily accessed to obtain a cross section of the stored product. Truck sampling options include push spears and vacuum spears, which are designed to take a profile section of the load. They are used by many growers and are easier to operate from an elevated platform. If adding an elevated platform to the facility, remember to add handrails to minimise the risk of falling.

Cleaning and facility maintenance

Maintaining good site hygiene is easier with a quality hard surface. Concrete pads are essential for silos to sit on but extended aprons can also assist cleaning spilt grain from loading and unloading.

 Common grain trap points include dump-pits, drainage or aeration channels and around silo bases.

Clean all grain off the site on a regular basis to avoid harbouring insects, which may infest stored grain. Ensure a water point is accessible for washing out silos after they are emptied. Grain vacuums are popular with owners of flat-bottomed silos to remove residual grain where sweep augers have not been able to reach.

Facility earthworks

Sample first: sampling spears are designed to take a representative sample of the load and are best mounted on an elevated platform.

When determining the requirement for earthworks, always allow a buffer around the pad for construction-vehicle movement. Raised pads are most common as they minimise the potential for water damage to the facility and stored grain. The height of the pad will typically vary according to the overall topography of the site relative to the landscape but 500mm above average topographic level is not uncommon.

Soil type impacts

Soil type can have a huge bearing on silo foundation thickness and requirements for facility earthworks. Foundations are normally engineered with depth of footing and reinforcing is determined according to the physical properties of the soil. Highly-reactive soils shrink and swell according to their level of moisture and typically require additional foundation engineering and reinforcing, which comes at a greater cost. As a rule of thumb, experienced silo-pad concreters assume soil type according to region for quoting purposes with slight variations dependent upon on-site requirements.


In addition to maintaining a raised, firm pad for the storage facility, plan for drainage to handle and direct run-off away from the pad. In some cases the natural topography of the site may assist free drainage while on flat sites, drainage channels may have to be formed to carry water away from the site. A well-designed pad for transportable cone-bottom silos will ensure water does not pool near the base structure, which can quickly rust out.


LightingLoading and out-loading is often carried out at night during harvest and effective lighting not only makes the job easier for drivers but also improves safety at the site. Efficient and robust forms of lighting, including LED, are suitable choices for short-throw requirements. If laying electrical cables underground, for aeration or auger drives, consider laying electrical cables for lighting at the same time.


With numerous market opportunities and volumes of information and data detailing specifications of stored grain increasing, facilities for data transfer and communication add value to any site plan, particularly if the site is to be equipped with a sampling and testing shed.

Clear communications: With increasing requirements for communications and data off site, consider communication requirements, including data transfer.

Planning to expand

It is rare any grower would set out to build a complete on-farm grain storage system from scratch. The capital requirement would be enormous and in most cases grain storage facilities grow with increasing farm productivity. The careful planning of a facility to be built in stages can ensure design aspects of the larger site are not overlooked when constructing these stages. It can also lead to savings through coordinated placement of pipes, electricals and concrete pads. Expansion is most commonly, and simplistically, an extension of a single line of silos, although variations include circles with a central receival and out-loading point. Single lines of silos offer the ability to run a single out-loading belt, which can feed grain into an elevator for out-loading or transfer to other silos.

When planning to expand, consider drying options including the ability to undertake batch drying or dedicated drying silos with ample airflow rates.

Also plan for aeration controller placement and associated electricals.

Staking out the facility

Everything can look good on plans, but it is important to physically stake out the site of grain facilities to ensure proportions have not been underestimated or overlooked. Driving pegs onto the site to indicate silo placement, pad borders and the positioning of roads and weighbridges can help visualise the suitability of the plan for the site.

Adapting existing facilities

In many cases, existing facilities are worked into the design to use existing infrastructure.Upgrading, including retro-sealing silos and sheds, can be an option to reduce the overall cost of storage per tonne, but remember to include ongoing maintenance costs for retro-sealed facilities. Offset placement of silos in lines parallel to lines of existing silos can be an option and can offer out-loading efficiencies. Apart from fitting in around older storages, the first modification to older silos should be the installation of an appropriately sized aeration fan and ducting.

On-site office and sampling sheds

An on-site office is ideal for keeping records and samples of stored grain. It can house expensive, sensitive testing equipment and be used as a crib-room for drivers and employees. Portable site offices are a common choice as they can be fitted with air-conditioning and are often pre-wired for electrical outlets. Used site offices regularly come up for sale on mining sites and can be bought at a fraction of the new price. As a minimal alternative, an on-site cabinet for load documentation and records will ensure hard copies of silo contents and load specification details are kept on site.

On-site office: An on-site sample shed can provide a home for sensitive test equipment, grain samples and records. Air conditioning is recommended.

Dump pits

Dump pits can be installed in combination with paddle or drag conveyors to quickly and easily take and elevate grain to load silos.

Carefully cover dump pits when not in use to keep water out and keep pits and surrounding areas clean to minimise contamination and spoilt grain.

Conveyor types

Numerous options for shifting grain around the site are available and each has benefits and disadvantages. Maximum angles of elevation vary between conveyors according to grain but figures are usually quoted for wheat. Augers are most common due to their portability and are one of the cheapest methods of elevating grain into a number of silos. Elevation angle and flight turn speed have a bearing on flow rates with higher elevation angles reducing throughput and impacting on hygiene. Hygiene can be compromised with lower throughput, as grain tends to sit between the auger flights. It is best removed by reversing the auger until all grain has been cleared.

Augers can occasionally damage split-prone grain — particularly old augers with worn flighting. Belted conveyors are the second most-commonly-used grain transfer method and are preferred by operators transferring damage-prone grain. Being a transportable unit, elevation angle is limited to the angle of repose of the grain. The angle of repose is a physical stacking property of a grain and varies between grain types. The repose angle is a measure of the angle of the sides of a conical grain pile from horizontal.

For example, the angle of repose for wheat is 27 degrees while canola is 22 degrees. Flow rates reduce as the angle of elevation increases to approach the repose angle. Belts are often cupped along the conveyor length to accommodate grain and hygiene is excellent with the design of a belted conveyor being self-cleaning. Bucket elevators are predominantly used to elevate grain vertically and are commonly used together with belted conveyors transferring grain horizontally, or splitters diverting grain down chutes through a gated manifold.

Bucket elevators are self-cleaning by design and are typically fixed position equipment Drag-chain conveyors or paddle conveyors use a series of paddles fixed to a loop of chain moving inside a conduit. Drag chains can elevate at any angle, including horizontal, and are largely self-cleaning, although corners of the chain-loop will normally require attention. Drag-chain conveyors are a permanent installation but are extendable for facility expansion.

Slick storage set-ups

Mark Hyde Andrew Simpson Lyndon Price David Maitland Rod Petersen Elliot Harris Harry Hyde Glen Milsted

Colin Bell

Useful resources

Grain storage specialists

Grain biosecurity contacts

Successful Storage in Grain Bags

Stored Grain Storage Bags

Bulk grain bags, also known as Silo Bags, can be a handy harvest storage option if used properly. A planned approach with careful management is essential.


  • Grain bags are best suited for short-term, high-volume grains to assist with harvest logistics.
  • Site planning and preparation is the first and most important step for successful storage.
  • Bulk grain bags are a higher risk form of storage compared with silos — requiring experience and best management practice.
  • Inspecting grain bags weekly, or more frequently, and patching holes will reduce the chance of spoilt grain from moisture or pests.

Bulk grain bags are best used for short-term storage (a few months maximum) to support harvest logistics.

Storing grain for longer periods requires:

  • Prior experience
  • A carefully prepared site
  • A method of sampling grain for quality monitoring
  • Regular inspections.

The capacity of grain bags varies with bag size, which generally ranges from 40 to 90 metres long, and anywhere from 100 to 300 tonnes depending on the type of grain and how much the bag is stretched during filling.

The material most commonly used for grain bags is a three-layer polyethylene — two white layers to protect against the ultraviolet rays and reflect heat and a black inner layer to block light.

Which grains?

Due to their short-term storage capacity and suitability for supporting harvest pressure, growers tend to use grain bags primarily for extending existing storage during high-yielding seasons of typically wheat, barley and sorghum.

Aeration cooling is not yet proven with grain bags. Storing canola or high-value legumes is not recommended.

Cereal grain quality is best preserved when the moisture content is below 12.5 per cent. Storing grain at higher moisture content in bags not only compromises grain quality but increases the risk of grain swelling and splitting the bag.

Being unable to aerate bags and having a large surface area exposed to heating from the sun means grain remains warm for months after harvest. This can affect seed germination rates and malt barley quality.

Storing grain at harvest temperatures of 30°C and above favours high insect reproduction rates, so take extra care with hygiene and monitoring.

Bulk grain bags are an effective form of storage when used in the right situations and when they are managed correctly.

Buying grain bags

  • Test bag quality by pushing your thumb through an edge of the bag — you will be able to make a subjective judgement as to whether it is high or poor quality. Test different brands before you buy.
  • Ensure the bag is UV stable for 12 months and complies with the ISO 9001 quality management system.
  • Make sure the bag has stretch indicators for accurate filling.
  • Ensure the grain bag is designed for grain not silage — different bags look similar and can be confused leading to disastrous results.

Testing and Guage

Choosing a site

  • Appropriate site selection is the first and most fundamental step in successful grain bag management.
  • Placing bags in different paddocks makes filling direct from the harvester or chaser bin easier but increases maintenance and monitoring time. This can compromise grain quality.
  • Bags located in individual paddocks can be challenging in wet weather.
  • A central, common storage site for bags is ideal for easier site preparation, monitoring, bag maintenance, vermin control and out-loading.
  • Select a hard, smooth, elevated site with a gentle slope where water can drain away.
  • Allow plenty of room around the grain bags for machinery access and trucks to turn around.
What a site: The ideal site for grain bags should be accessible even when wet. It should be clear of sharp objects and firmly-rolled so water can drain away freely.
What a site: The ideal site for grain bags should be accessible even when wet. It should be clear of sharp objects and firmly-rolled so water can drain away freely.

Preparing the site

  • Grade and roll the site, removing sticks, rocks or sharp objects.
  • Clear, firm ground makes operating the filling and emptying machines easier with less chance of brakes skidding.
  • A firmly-rolled site helps drainage and prevents water pooling where the grain bag has sunken into soft ground.
  • Anything that can puncture the bag is a threat and must be removed. Set up the site away from rocks, sticks, trees (they drop branches and harbour birds) and away from sand hills or long grass where rabbits, mice and foxes shelter.
  • Anecdotally, a thin sprinkle of urea can be spread on the ground where the bag is to be laid to deter mice from burrowing under it.

Setting up the filling machine

The most common filling machines are power take-off (PTO) driven, forcing grain into the bag, stretching it by about 10 per cent as it’s laid. A more recent development is the gravity filling design, which requires no power or tractor to operate and relies purely on gravity to fill and stretch the bag.

Make sure the machine is clean before filling the bags.

Grain pests, such as weevils and other insects, can survive in small amounts of grain left in equipment from the previous season. If the machine is not clean, these pests can infest the new season’s grain and will multiply and spread through the entire grain bag

Fitting the bag onto the machine with two people saves time and reduces the chance of injury. When setting up the bag on the filling machine, ensure the stretch markers are on a side where they can be seen and measured when the bag is filling. Once filled, any holes in the bag will allow grain to absorb moisture from the ground.

Options include:

  • sealing the ends of the grain bag with a heat sealer, or
  • clamping the ends between two lengths of timber or steel, rolling each end around the timber then tucking the bag under itself with about a metre overlap.

The squarer the starting end of the bag, the easier it is to empty with less shovelling — a cable tie around the end is NOT a good idea.

Before filling the bag, use a string line to mark a straight path along the full length of the bag. A straight bag is a lot easier to empty than a curved bag.

Fill-her-up thanks: Grain bags can be filled straight from the harvester, or from a truck with a short auger and hopper system, but the most convenient is filling from a chaser or mother bin.
Fill-her-up thanks: Grain bags can be filled straight from the harvester, or from a truck with a short auger and hopper system, but the most convenient is filling from a chaser or mother bin.

Filling the bag

Patience and accuracy during filling will make emptying the bag much easier, reduce maintenance on the bag during the storage period and result in less spills and fewer stops to realign machinery.

  • Keep the bag filling evenly and straight to avoid creases — mice tend to attack creases.
  • Adjust the brakes and direction often and in small increments.
  • Avoid over-filling (over-stretching) the bag as extra strain makes it more prone to holes, splits and tears.
  • Remember, the polyethylene bags will stretch more easily when filled with warm grain on hot days.
  • Bags can be filled straight from the harvester, but operators may be tempted to rush, which leads to a poor job and increases the risk of an accident. (ie damage to machinery or operators).
  • Stop filling the bag while there is still plenty of bag to seal and re-attach to the emptying machine — about four metres is a good rule of thumb.
  • As with the starting end, heat seal or clamp the bag end to keep moisture out, then tuck the excess bag under itself and cover with soil to stop it flapping in the wind.

Barrier of Defense

Site security and maintenance

Site security starts with hygiene. Cleaning the site after filling will not only remove harbours for grain insects, it will remove feed that attracts mice and wildlife. After cleaning up around the site, establish mice baiting stations along the length of each bag and put up signs to warn people of the poison.

Keep the site free of grass by spraying it regularly to remove cover for mice and wildlife. A sturdy fence, even an electric fence, around the bags can help prevent animals accessing the bags and chewing or walking on them. Even if there are no livestock in the paddock, remember there is always the potential for stray livestock or wild animals to cause a lot of damage in a short time.

Checking as often as twice daily may be required if vermin are plentiful during wet weather. During normal conditions check at least weekly. Patch any tears or punctures with quality tape or silicone to prevent moisture entering the grain bulk.

Wet weather warning: Grain bags can be emptied straight into a truck but if the paddock is wet, grain will have to be transferred from the bag to the truck with a chaser bin.
Wet weather warning: Grain bags can be emptied straight into a truck but if the paddock is wet, grain will have to be transferred from the bag to the truck with a chaser bin.

Emptying the bag

When making the initial cut in the bag for out-loading, place a piece of tape horizontally across the bag below where it is stretched tight at the top. Make the first cut perpendicular to the bag just below the tape. Do not make the cut parallel to the bag as there is potential for it to split up the entire length of the bag, exposing the grain and making it difficult to pick up.

As previously stated for filling the bag, frequent, small adjustments to align the machine and roller speeds are better than large adjustments. When the bag is almost empty and there’s not much weight left in it, the unloading machine may drag the bag towards itself. This can cause tears from the ground or from over stretching. To prevent this, drive the tractor slowly backwards as the last bit of the bag is emptied.

Clean up

Clean grain residues from machinery used for grain handling to prevent reinfestation with insect pests next season. Structural treatments are a wise addition to a thorough clean down.

An inert dust such as diatomaceous earth (DE), can be blown into the machinery to prevent insects harbouring during the off season.

Site clean-up is vital for success. Spilt piles of grain and leftover small bags of grain provide an ideal harbour for insects to live and breed.

Safety around grain bags

Filling and emptying grain bags poses a number of safety hazards, exacerbated by the fact that during harvest people are usually tired and in a hurry. Always follow machinery manufacturer instructions and consult your State occupational health and safety authority for advice.

  • Treat all operating machinery with respect — keep a distance from machines and always have room to take a step away if needed.
  • Think before you make any adjustments or movements on machinery.
  • Ensure anyone on-site is standing clear of the filling machine and tractor before adjusting the brakes as it can lurch forward at any time. Making small adjustments reduces the risk of the machine lurching.
